Asetek SimSports Load Cell Handbrake
Fulfillment within 3 business days.
Seasonal demand may extend delivery times.
Please refer to each product’s Black Friday delivery schedule above.
Asetek SimSports Load Cell Handbrake
Sale price$179.00 USD
Asetek SimSports Load Cell Handbrake
200 kg of load-cell precision. A progressive spring and elastomer stack. Ultra-precise response and feel. Brake like the pros.
Every aspect of your racing experience matters. Braking seems simple; stop or go. But when you experience our high-precision handbrake built for exacting car control, you won’t want to drive any other way. Featuring a 200 kg load-cell for precise force-based input and tuneable resistance, it’ll keep you in control whether you’re throwing the car sideways or drifting corners.
What is in the box
- Dual Moder Shifter (x1)
- Cockpit Mounting Bracket (x1)
- USB-A to USB-C Cable (x1)
- USB-C to USB-C Cable (x1)
- Connection Bracket
Specification
| Load Cell — Maximum Load | 200 kg (440.92 lbs) |
| Resolution | 16 Bit |
| Technology | |
| Two-Stage Resistance System | Tunable elastomer and spring stack |
| Modes/Software | |
| Modes | Analog / Digital |
| Software | RaceHub |
| Mounting | |
| Mounting Holes | 4xM6 threaded T-nuts |
| Mounting | Both left-hand and right-hand drive |
| Pattern Width | 80 mm (3.15 in) |
| Pattern Length | Variable length 30–69 mm (1.18–2.72 in) |
| Dimensions | |
| Size | 133 × 132 × 360 mm (5.24 x 5.20 x 14.17 in) |
| Weight | 2.5 kg (5.51 lbs) |
| Gear Knob | M10 |
| Connections | |
| Connection to Host | USB Type-C |
| Power Input | 5 V, 500 mA (Max. 2.5 W) |
| Warranty | |
| Warranty | 60 Months |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) (Room Temperature) |
| Tested | 1,000,000 Brake Cycles |
